BRAVO 40 – 40A MPPT Solar Charge Controller 12V/24V
40A MPPT controller for rvs, trailers and cabins.
SKU:RS-MPPT40P
Regular price
$159.99 USD
40A MPPT charge controller.
12/24V Auto battery systems.
Handles 600 Watt (12V) / 1200 Watt (24V) of panels.
IP43 for Inside PCBA, IP22 for Connection Area rated.
Need help choosing the right kit?
Talk to a Solar Expert:
1-332-291-6885
Quantity
Quantity
Guaranteed Safe Checkout
Deliver to
Get it between
Product Information
40A MPPT Solar Charge Controller for RVs, Trailers and Cabins
An MPPT controller tracks the array's maximum power point and converts the surplus voltage into charging current, so it harvests more than a PWM unit from the same panels — most noticeably in cold or low light, and whenever panel voltage sits well above battery voltage.
Keep the array within 600 Watt (12V) / 1200 Watt (24V). Panel open-circuit voltage must stay under 100V DC — check this in cold weather, when Voc rises above the rated figure. It charges Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO.
Rated IP43 for Inside PCBA, IP22 for Connection Area. Mount it close to the battery on a vertical surface with airflow around the heatsink, and wire battery first, then panels.
| Specification | Value |
|---|---|
| System Nominal Voltage | 12/24V Auto |
| Max. PV Open Circuit Voltage | 100V DC |
| Charging Technology | MPPT |
| Max PV Charging Current | 40A |
| Max. Recommended PV Input Power | 600 Watt (12V) / 1200 Watt (24V) |
| Charge Conversion Efficiency | ≤98% |
| MPPT Tracking Efficiency | >99.5% |
| Battery Type Preset | Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO |
| Housing Case Color | Black / Grey |
| IP Grade | IP43 for Inside PCBA, IP22 for Connection Area |
| Dimensions | 7.7 × 5.5 × 2.9 in |
| Net Weight | 2.58 lb |
| Package Dimensions | 10 × 7 × 5 in |
| Gross Weight | 4 lb |
- 1 x BRAVO 40
- Mounting or connection hardware as listed in the specifications
- User manual
Free Shipping
On all orders
30-Day Returns
Hassle-free returns
25 Year Warranty
On panels & more
Secure Payments
100% protected
Frequently Asked Questions
How many panels can I connect?
Keep the array within 600 Watt (12V) / 1200 Watt (24V). Watts alone are not the whole story — the panels' combined open-circuit voltage must also stay under 100V DC.
MPPT or PWM — which do I need?
MPPT harvests more, especially when panel voltage is well above battery voltage or in cold and low light, and it is the better choice for larger or 24V arrays. PWM costs less and suits small systems where panel and battery voltage are closely matched. This unit is MPPT.
Which batteries does it charge?
Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO. Set the correct battery profile before first charge — using the wrong profile shortens battery life.
